Innovative technology makes these models stand out, such as the two-handed safety operation, the fast cutting speed for high work efficiency, stepless adjustable cutting stroke as well as a log lifter as part of the standard accessories.
Scope of delivery Log splitter Bernardo HS 30 Z
- Two-handed safety operation
- Three-point mounting with attachment pins
- Log lifter
- PTO shaft with cover
- Oil filling
- Carriage
- Splitting wedge
Features Log splitter Bernardo HS 30 Z
- Comes complete with log lifter for the uplifting of heavy, large logs and stabilization of cut logs
- Allows for cutting of short and long logs up to 1100 mm
- High quality powder coating ensures scratch proof surface
- Large splitting wedge features solid, durable plastic guide
- Stepless adjustable cutting stroke allows for less time consumption
- Low base plate with bevelled edge enables more convenient loading of large logs
- Lowerable cylinder reduces space requirements and simplifies transport
- Powerful hydraulic unit features high quality pressure hoses
Technical details Log splitter Bernardo HS 30 Z
| Max. capacity | 30 to |
| Log length | 560 – 1100 mm |
| Log diameter | 80 – 400 mm |
| Ram travel max. | 948 mm |
| Forward speed* | 12,5 cm/sec |
| Working speed* | 3,7 cm/sec |
| Return speed* | 6,7 cm/sec |
| Hydraulic pressure | 26,1 Mpa |
| Hydraulic tank | 30 l |
| Drive | PTO |
| Power take-off speed | 540 rpm |
| Tractor capacity | > 20 HP |
| Machine dimension (L x W x H) | 1400 x 1500 x 2500 mm |
| Weight approx. | 332 kg |
| |
* Varying speed, depending on performance of tractor
