The DC 180 powerful, transportable dust collector improves the performance of your wood working machines significantly and it will keep your workspace free from chips and sawdust.
Scope of delivery Dust collectors Bernardo DC 180 - 230 V
Dust collectors Bernardo DC 180 - 230 V
Features Dust collectors Bernardo DC 180 - 230 V
- Connect to fixed or mobile wood working machines
- Maximum extraction force at minimum space requirements
- Powerful motor and fan wheel for optimal extraction force
- Carriage allows for easy transport
- Increases capacity of your wood working machines
- ABS-plastic, shock-resistant fan housing
Technical details Dust collectors Bernardo DC 180 - 230 V
|
Capacity
|
850 m³/h
|
|
Filter area
|
0,8 m²
|
|
Low pressure max.
|
700 Pa
|
|
Inlet diameter
|
100 mm
|
|
Waste sack volume
|
56 l
|
|
Idle speed
|
2850 rpm
|
|
Sound pressure
|
80 dB
|
|
Motor power output S1 100%
|
0,55 KW (0,75 HP)
|
|
Motor power input S6 40%
|
0,75 kW (1,0 HP)
|
|
Voltage
|
230 V / 50 Hz
|
|
Machine dimension (W x D x H)
|
770 x 410 x 1660 mm
|
|
Weight approx.
|
18 kg
|
