The downdraft tables of the AT-series guarantee a clean work environment in single and small series production. A fan at the table allows for decent extraction of the sanding dust.
Scope of delivery Dust collector for metal chips Bernardo AT 1500 HM
- On-Off switch
- 4x filter (wood / metal)
- Rubber table protection
- Chip drawer
- 6x workpiece fence
Features Dust collector for metal chips Bernardo AT 1500 HM
- State-of-the-art design – allows for optimal working conditions and clean air at work
- Optimal filtration of extracted air, circulated back into work space
- Optimal fan design guarantees top efficiency and smooth run
- Suitable for sanding of any type of workpieces
- Extractable chip drawer at the front of machine
- Complete with hinged side panels for longer workpieces
- Installed fan, additional dust collector not necessary
- Rubber table protection guarantees scratch-free work
- Statically and dynamically balanced steel fan wheels
Technical details Dust collector for metal chips Bernardo AT 1500 HM
| Table size | 1550 x 550 mm |
| Table height | 825 mm |
| Max. load capacity | 225 kg |
| Capacity max. | 2x 2500 m³/h |
| Motor power | 2x 0,75 kW (2x 1,0 HP) |
| Voltage | 230 V / 50 Hz |
| Machine dimension (W x D x H) | 1660 x 620 x 900 mm |
| Weight approx. | 105 kg |
